5DISPlay Subsystem
232 N1911A/1912A P-Series Power Meters Programming Guide
Parameters
Example
Reset Condition
On reset, the N1911A power meter upper window is DIGital and the
lower window ANALog. For the N1912A power meter, the defaults for the
Item Description/Default Range of Values
character_data Sets the window format:
• DIGital: sets the window display to
digital. This setting is the same as
SNUMeric.
• ANALog: sets the window display to
analog using the currently SELected
measurement.
• SNUMeric: sets the window display to
single numeric. The currently SELected
measurement is displayed. This setting is
the same as DIGital.
• DNUMeric: sets the window display to
dual numeric.
• TRACe: trace display using the currently
SELected measurement. Used to
determine the channel from which the
trace is taken.
• CTRAce: sets the display to expanded
CCDF window.
• CTABle: sets the window display to
CCDF table.
DIGital
ANALog
SNUMeric
DNUMeric
TRACe
CTRAce
CTABle
DISP:WIND2:FORM DIG This command sets the lower window to a
digital display.
