SYSTem Subsystem 12
N1911A/1912A P-Series Power Meters Programming Guide 537
[SENS[1]]|SENS2:SWE[1]|2|3|4
:TIME
Gate 1: 520 µs
Gates 2 - 4: 0
Length of time gated period for time
gated measurements.
Trigger setup
TRIG[:SEQ[1]|2]:SOUR INT1 Trigger source set up and acquisition
mode continuous triggering
INIT:CONT ON
TRIG[:SEQ]:LEV:AUTO OFF Disable automatic setting of the trigger
level
TRIG[:SEQ]:LEV –15 dBm Power level
TRIG[:SEQ]:SLOP POS Trigger event recognized on the rising
edge of a signal
TRIG[:SEQ]:DEL 0 s Delay between recognition of trigger
event and start of a measurement
TRIG[:SEQ]:HOLD 4275 µs Trigger holdoff
TRIG[:SEQ]:HYST 3 dB Hysteresis
Range
[SENS[1]]|SENS2:POW:AC:RANG:AUTO OFF Auto range off
[SENS[1]]|SENS2:POW:AC:RANG UPPER Range set to upper
Averaging
[SENSe[1]]|SENSe2:AVER[:STATe] ON Averaging On
[SENSe[1]]|SENSe2:AVER:COUN 64 Averaging set to 64
Step detection
[SENSe[1]]|SENS2:AVER:SDET 1 Step detection enabled
Trace setup
SENSe[1]|2:TRAC:LIM:UPP +20 dBm Maximum power
SENSe[1]|2:TRAC:LIM:LOW –35 dBm Minimum power
[SENS[1]]|SENS2:TRAC:OFFS
:TIME <numeric_value>
–40 µs Delay between delayed trigger point and
the start of the trace
[SENS[1]]|SENS2:TRAC:TIME
<numeric_value>
700 µs Length of the trace
Command Setting Comments
The Range setting in Table 12-30 is only applicable for E-Series power sensor and N8480
Series power sensor (excluding Option CFT)
