12 SYSTem Subsystem
584 N1911A/1912A P-Series Power Meters Programming Guide
Lower window Dual numeric Dual numeric Dual numeric
Upper window/lower measurement (UL)
Feed DEF
Gate 1 primary channel
*
Gate 1 primary channel
*
(Channel A)
Measurement DEF Peak Peak
Lower window/upper measurement (LU)
Feed
Gate 1 primary channel
*
Gate 1 primary channel
*
Gate1 secondary channel*
(Channel B)
Measurement Peak Pk-to-Avg Avg
Lower window/lower measurement (LL)
Feed
Gate 1 primary channel
*
Secondary channel
*
Gate1 secondary channel
*
(Channel B)
Measurement Pk-to-Avg Avg Pk-to-Avg
* For further information refer to “Primary and Secondary Channels” on page 526.
Function Secondary Channel Sensor
No Sensor Non P-Series or E9320
Sensor
P-Series and E9320
Sensor
