TRACe Subsystem 13
N1911A/1912A P-Series Power Meters Programming Guide 613
Parameters
Example
Error Messages
If TRAC:STAT is off, the error –221, “Settings Conflict” occurs.
Item Description/Default Range of
Values
character_data • HRESolution: high resolution. The complete capture
buffer at the internal sample rate. The number of points in
this trace is not fixed, as it is affected by the
SENS:TRACe:TIMe setting.
• MRESolution: medium resolution. A subset of the
capture buffer - the buffer contents are decimated
1
to 1000
data points.
• LRESolution: low resolution. A subset of the capture
buffer - the buffer contents are decimated
1
to provide 230
data points. This is the same number of data points as the
power meter uses to display the trace on the front panel.
Hence, the LRES command can be used to replicate the
power meter’s display.
HRES
MRES
LRES
TRAC:DATA? HRES This command returns the trace data for
Channel A at high resolution.
