Interfaces Local Area Networks(LANs)
IX20 User Guide
219
a. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click Network >Interfaces.
4. Click to expand an existing LAN, or create a new LAN. See Configure a Local Area Network
(LAN).
5. Disable the DHCPserver, if it is enabled:
a. Click to expand IPv4 >DHCP server.
b. Click Enable to toggle off the DHCPserver.
6. Click to expand DHCP relay.
7. For Add DHCP Server:, click .
8. For DHCP server address, typethe IPaddress of the relay server.
9. Repeat for each additional DHCPrelay server.
10. Click Apply to save the configuration and apply the change.
Command line
1. Select the device in Remote Manager and click Actions> Open Console, or log into the IX20
local command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to accessthe Admin CLI.
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. Add a DHCP relay server to an existing LAN. For example, to add a server to a LAN named my_
lan:
(config)> add network interface my_lan ipv4 dhcp_relay end
(config network interface lan1 my_lan dhcp_relay 0)>
See Configure a Local Area Network (LAN) for information about creating a LAN.
