Digi IX20 User Manual

Virtual PrivateNetworks(VPN) IPsec
IX20 User Guide
523
/network/interface/defaultip
/network/interface/defaultlinklocal
/network/interface/eth1
/network/interface/eth2
/network/interface/loopback
Current value:
(config vpn ipsec tunnel ipsec_example surelink tests 1)>
other_interface
ii. Set the interface. For example:
(config vpn ipsec tunnel ipsec_example surelink tests 1)>
other_interface /network/interface/eth1
(config vpn ipsec tunnel ipsec_example surelink tests 1)>
l
Set the typeof IPconnection:
(config vpn ipsec tunnel ipsec_example surelink tests 1)>
other_ip_version value
(config vpn ipsec tunnel ipsec_example surelink tests 1)>
where value is one of:
o
any: Either the IPv4 or IPv6 connection must be up.
o
both: Both the IPv4 or IPv6 connection must be up.
o
ipv4 The IPv4 connection must be up.
o
ipv6: The IPv6 connection must be up.
l
The status required for the test to past.
(config vpn ipsec tunnel ipsec_example surelink tests 1)>
other_status value
(config vpn ipsec tunnel ipsec_example surelink tests 1)>
where value is one of:
o
up: The test will passonly if the referenced interface is up and passing its
own SureLink tests(if applicable).
o
down: The test will passonly if the referenced interface isdown or failing its
own SureLink tests(if applicable).
f. Repeat for each additional test.
6. Add recovery actions:
a. Type ... to return to the root of the configuration:
(config vpn ipsec tunnel ipsec_example surelink tests 1)> ...
(config)>
b. Add a recovery action:
(config)> add vpn ipsec tunnel ipsec_example surelink actions end
(config vpn ipsec tunnel ipsec_example surelink actions 0)>

Digi IX20 Specifications

General

Category	Wireless Router
Cellular Connectivity	4G LTE
Ethernet Ports	4
Wi-Fi	802.11ac
SIM Slots	2
WAN Ports	1
LAN Ports	3
Weight	0.5 kg
Operating Temperature	-40°C to +70°C (-40°F to +158°F)
