B.3 Device Specific Information
The various address bus, data bus and bus control signals are sourced from different device signals
depending on the MPC5500 family being used as detailed in the following sections.
CAL_CS[1] Chip Select No Connect CS[1]_
ADDR[9]_
GPIO[1]
CAL_CS
[2] Chip Select BR
1
_
CAL_ADDR[10]_
FEC_MDC_
CAL_CS
[2]_
GPIO[72]
CS
[2]_
ADDR[10]_
GPIO[2]
CAL_CS
[3] Chip Selects BG
1
_
CAL_ADDR[11]_
FEC_MDIO_
CAL_CS
[3]_
GPIO[73]
CS
[3]_
ADDR[11]_
GPIO[3]
CAL_DATA[0:15] Data Bus DATA[16:31]_
FEC_(signals)
2
_
CAL_DATA[0:15]_
GPIO[44:59]
DATA[0:15]_
GPIO[28:43]
CAL_OE
Output Enable OE_
GPIO[68]
OE_
GPIO[68]
CAL_RD_WR Read/Write RD_WR_
GPIO[62]
RD_WR_
GPIO[62]
CAL_TS Transfer Start TS_
GPIO[69]
TS_
GPIO[69]
CAL_TA
Transfer Acknowledge TA_
GPIO[70]
TA_
GPIO[70]
CAL_WE/BE[0:1] Write/Byte Enable WE[/BE[2:3]
3
_
CAL_WE/BE[0:1]_
GPIO[66:67]
WE/BE[0:1]_
GPIO[64:65]
Clock Synthesizer (1)
CLKOUT System Clock Output CLKOUT CLKOUT
1
The BR and BG functions are not implemented on the MPC5553 and are replaced by FEC and calibration functions. The
pin name on the ball map, however, does remain BR
and BG. The primary functions for these pins are CAL_ADDR[10]
and CAL_ADDR[11], respectively.
2
Refer to the Signals chapter for a complete list of FEC signals.
3
The function for the WE/BE[2:3]_CAL_WE/BE[0:1]_GPIO[66:67] pins is specified in the SIU. When configured for EBI,
the write enable or byte enable operation is specified in the EBI_BR0 through EBI_BR3 registers. When configured for
the Calibration bus, the write enable or byte enable operation is specified in the EBI_CAL_BR0 through EBI_CAL_BR3
registers for each chip select region.
Table B-1. Calibration Bus Signals (Continued)
VertiCal Signal Name Function
Device Implementation Signal Name
MPC5553 MPC5554
