Appendix A
MPC5553/MPC5554 Register Map
A.1 Module Base Addresses
Table A-1. Module Base Addresses
Module Base Address Page
Peripheral Bridge A (PBRIDGE_A) 0xC3F0_0000 Page A-2
Frequency Modulated Phase-Locked Loop (FMPLL) 0xC3F8_0000 Page A-2
External Bus Interface (EBI) 0xC3F8_4000 Page A-2
Flash Module and Flash Bus Interface Unit (FLASH) 0xC3F8_8000 Page A-3
System Integration Unit (SIU) 0xC3F9_0000 Page A-3
Enhanced Modular Input/Output Subsystem (eMIOS) 0xC3FA_0000 Page A-25
Enhanced Time Processing Unit (eTPU) 0xC3FC_0000 Page A-25
Peripheral Bridge B (PBRIDGE_B) 0xFFF0_0000 Page A-35
System Bus Crossbar Switch (XBAR) 0xFFF0_4000 Page A-36
Error Correction Status Module (ECSM) 0xFFF4_0000 Page A-37
Enhanced Direct Memory Access (eDMA) 0xFFF4_4000 Page A-38
Interrupt Controller (INTC) 0xFFF4_8000 Page A-42
Fast Ethernet Controller (FEC) — in MPC5553 only 0xFFF4_C000 Page A-53
Enhanced Queued Analog-to-Digital Converter (eQADC) 0xFFF8_0000 Page A-54
Deserial / Serial Peripheral Interface (DSPIx) 0xFFF9_0000 (DSPI A)
1
0xFFF9_4000 (DSPI B)
0xFFF9_8000 (DSPI C)
0xFFF9_C000 (DSPI D)
1
MPC5554 Only
Page A-58
Enhanced Serial Communication Interface (eSCIx) 0xFFFB_0000 (A)
0xFFFB_4000 (B)
Page A-59
FlexCAN2 Controller Area Network (CANx) 0xFFFC_0000 (FlexCAN A)
0xFFFC_4000 (FlexCAN B)
1
0xFFFC_8000 (FlexCAN C)
Page A-59
Boot Assist Module (BAM) 0xFFFF_C000 Page A-60
