Transfer control descriptor register 40 TCD40 256-bit Base + 0x1500
Transfer control descriptor register 41 TCD41 256-bit Base + 0x1520
Transfer control descriptor register 42 TCD42 256-bit Base + 0x1540
Transfer control descriptor register 43 TCD43 256-bit Base + 0x1560
Transfer control descriptor register 44 TCD44 256-bit Base + 0x1580
Transfer control descriptor register 45 TCD45 256-bit Base + 0x15A0
Transfer control descriptor register 46 TCD46 256-bit Base + 0x15C0
Transfer control descriptor register 47 TCD47 256-bit Base + 0x15E0
Transfer control descriptor register 48 TCD48 256-bit Base + 0x1600
Transfer control descriptor register 49 TCD49 256-bit Base + 0x1620
Transfer control descriptor register 50 TCD50 256-bit Base + 0x1640
Transfer control descriptor register 51 TCD51 256-bit Base + 0x1660
Transfer control descriptor register 52 TCD52 256-bit Base + 0x1680
Transfer control descriptor register 53 TCD53 256-bit Base + 0x16A0
Transfer control descriptor register 54 TCD54 256-bit Base + 0x16C0
Transfer control descriptor register 55 TCD55 256-bit Base + 0x16E0
Transfer control descriptor register 56 TCD56 256-bit Base + 0x1700
Transfer control descriptor register 57 TCD57 256-bit Base + 0x1720
Transfer control descriptor register 58 TCD58 256-bit Base + 0x1740
Transfer control descriptor register 59 TCD59 256-bit Base + 0x1760
Transfer control descriptor register 60 TCD60 256-bit Base + 0x1780
Transfer control descriptor register 61 TCD61 256-bit Base + 0x17A0
Transfer control descriptor register 62 TCD62 256-bit Base + 0x17C0
Transfer control descriptor register 63 TCD63 256-bit Base + 0x17E0
Reserved — — (Base + 0x1800)-
0xFFF4_7FFF
Interrupt Controller (INTC)
0xFFF4_8000 Chapter 10,
“Interrupt
Controller (INTC)”
Module configuration register INTC_MCR 32-bit Base + 0x0000
Reserved — — Base + (0x0004-0x0007)
Current priority register INTC_CPR 32-bit Base + 0x0008
Reserved — — Base + (0x000C-0x000F)
Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)
