MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
Freescale Semiconductor A-43
interrupt acknowledge register INTC_IACKR 32-bit Base + 0x0010
Reserved — — Base + (0x0014-0x0017)
End of interrupt register INTC_EOIR 32-bit Base + 0x0018
Reserved — — Base + (0x001C-0x001F)
Software set/clear interrupt register 0 INTC_SSCIR0 8-bit Base + 0x0020
Software set/clear interrupt register 1 INTC_SSCIR1 8-bit Base + 0x0021
Software set/clear interrupt register 2 INTC_SSCIR2 8-bit Base + 0x0022
Software set/clear interrupt register 3 INTC_SSCIR3 8-bit Base + 0x0023
Software set/clear interrupt register 4 INTC_SSCIR4 8-bit Base + 0x0024
Software set/clear interrupt register 5 INTC_SSCIR5 8-bit Base + 0x0025
Software set/clear interrupt register 6 INTC_SSCIR6 8-bit Base + 0x0026
Software set/clear interrupt register 7 INTC_SSCIR7 8-bit Base + 0x0027
Reserved — — Base + (0x0028-0x003F)
Priority select register 0 INTC_PSR0 8-bit Base + 0x0040
Priority select register 1 INTC_PSR1 8-bit Base + 0x0041
Priority select register 2 INTC_PSR2 8-bit Base + 0x0042
Priority select register 3 INTC_PSR3 8-bit Base + 0x0043
Priority select register 4 INTC_PSR4 8-bit Base + 0x0044
Priority select register 5 INTC_PSR5 8-bit Base + 0x0045
Priority select register 6 INTC_PSR6 8-bit Base + 0x0046
Priority select register 7 INTC_PSR7 8-bit Base + 0x0047
Priority select register 8 INTC_PSR8 8-bit Base + 0x0048
Priority select register 9 INTC_PSR9 8-bit Base + 0x0049
Priority select register 10 INTC_PSR10 8-bit Base + 0x004A
Priority select register 11 INTC_PSR11 8-bit Base + 0x004B
Priority select register 12 INTC_PSR12 8-bit Base + 0x004C
Priority select register 13 INTC_PSR13 8-bit Base + 0x004D
Priority select register 14 INTC_PSR14 8-bit Base + 0x004E
Priority select register 15 INTC_PSR15 8-bit Base + 0x004F
Priority select register 16 INTC_PSR16 8-bit Base + 0x0050
Priority select register 17 INTC_PSR17 8-bit Base + 0x0051
Priority select register 18 INTC_PSR18 8-bit Base + 0x0052
Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)
Register Description Register Name
Used
Size
Address Reference
