1.4 MPC5500 Family Comparison
Table 1-1. MPC5500 Family Members
MPC5500 Device MPC5533 MPC5534 MPC5553 MPC5554 MPC5565 MPC5566 MPC5567
Power Architecture Core e200z3 e200z3 e200z6 e200z6 e200z6 e200z6 e200z6
Variable Length Instruction Support Yes Yes No No Yes Yes Yes
Cache None None 8k
Unified
1
32k
Unified
2
8k
Unified
1
32k
Unified
3
8k
Unified
1
Memory Management Unit (MMU) 16 entry 16 entry 32 entry 32 entry 32 entry 32 entry 32 entry
Crossbar 4x5 4x5 4x5 3x5 3x5 4x5 5x5
Core Nexus Class 3+
(NZ3C3)
Class 3+
(NZ3C3)
Class 3+
(NZ6C3)
Class 3+
(NZ6C3)
Class 3+
(NZ6C3)
Class 3+
(NZ6C3)
Class 3+
(NZ6C3)
SRAM 48k 64k 64k 64k 80k 128k 80k
Flash Main Array 768k
4
1M
4
1.5M
5
2M
5
2M
5
3M
5
2M
5
Shadow Block1k1k1k1k1k1k1k
External Bus
(EBI)
Data Bus 16-bit
6
16 bit
6
32 bit
6
32 bit
6
32-bit
6
32-bit
6
32-bit
6
Address Bus 2424242426
7
26
7
26
7
Calibration Bus Yes Yes Partial No Yes Yes Yes
Direct Memory Access (DMA) 32
channel
32
channel
32
channel
64
channel
32
channel
64
channel
32
channel
DMA Nexus None None Class 3 Class 3 Class 3 Class 3 Class 3
Serial 1222222
eSCI_A Yes Yes Yes Yes Yes Yes Yes
eSCI_B No Yes Yes Yes Yes Yes Yes
Controller Area Network (CAN) 2 2 2 3 3
8
4
8
5
8
CAN_A 64 buf 64 buf 64 buf 64 buf 64 buf 64 buf 64 buf
CAN_B No No No 64 buf 64 buf 64 buf 64 buf
CAN_C 64 buf 64 buf 64 buf 64 buf 64 buf 64 buf 64 buf
CAN_D No No No No No 64 buf 64 buf
CAN_E NoNoNoNoNoNo64 buf
SPI 2334343
DSPI_A No No No Yes No Yes No
D S P I _ B N o Ye s Ye s Ye s Ye s Ye s Ye s
D S P I _ C Ye s Ye s Ye s Ye s Ye s Yes Ye s
D S P I _ D Ye s Ye s Ye s Ye s Ye s Yes Ye s
eMIOS 0
channel
24
channel
24
channel
24
channel
24
channel
24
channel
24
channel
eTPU 32
channel
32
channel
32
channel
64
channel
32
channel
64
channel
32
channel
eTPU_A Yes Yes Yes Yes Yes Yes Yes
eTPU_B No No No Yes No Yes No
Code Memory 12k 12k 12k 16k 12k 20k 12k
