Deserial / Serial Peripheral Interface (DSPIx)
0xFFF9_0000 (DSPI A)
2
0xFFF9_4000 (DSPI B)
0xFFF9_8000 (DSPI C)
0xFFF9_C000 (DSPI D)
Chapter 20,
“Deserial Serial
Peripheral
Interface (DSPI)”
Module configuration register DSPIx_MCR 32-bit Base + 0x0000
Reserved — — Base + (0x0004-0x0007)
Transfer count register DSPIx_TCR 32-bit Base + 0x0008
Clock and transfer attribute register 0 DSPIx_CTAR0 32-bit Base + 0x000C
Clock and transfer attribute register 1 DSPIx_CTAR1 32-bit Base + 0x0010
Clock and transfer attribute register 2 DSPIx_CTAR2 32-bit Base + 0x0014
Clock and transfer attribute register 3 DSPIx_CTAR3 32-bit Base + 0x0018
Clock and transfer attribute register 4 DSPIx_CTAR4 32-bit Base + 0x001C
Clock and transfer attribute register 5 DSPIx_CTAR5 32-bit Base + 0x0020
Clock and transfer attribute register 6 DSPIx_CTAR6 32-bit Base + 0x0024
Clock and transfer attribute register 7 DSPIx_CTAR7 32-bit Base + 0x0028
Status register DSPIx_SR 32-bit Base + 0x002C
DMA/interrupt request select and enable register DSPIx_RSER 32-bit Base + 0x0030
Push TX FIFO register DSPIx_PUSHR 32-bit Base + 0x0034
Pop RX FIFO register DSPIx_POPR 32-bit Base + 0x0038
Transmit FIFO registers 0 DSPIx_TXFR0 32-bit Base + 0x003C
Transmit FIFO registers 1 DSPIx_TXFR1 32-bit Base + 0x0040
Transmit FIFO registers 2 DSPIx_TXFR2 32-bit Base + 0x0044
Transmit FIFO registers 3 DSPIx_TXFR3 32-bit Base + 0x0048
Reserved — — Base + (0x004C-0x007B)
Receive FIFO registers 0 DSPIx_RXFR0 32-bit Base + 0x007C
Receive FIFO registers 1 DSPIx_RXFR1 32-bit Base + 0x0080
Receive FIFO registers 2 DSPIx_RXFR2 32-bit Base + 0x0084
Receive FIFO registers 3 DSPIx_RXFR3 32-bit Base + 0x0088
Reserved — — Base + (0x008C-0x00BB)
DSI configuration register DSPIx_DSICR 32-bit Base + 0x00BC
DSI serialization data register DSPIx_SDR 32-bit Base + 0x00C0
DSI alternate serialization data register DSPIx_ASDR 32-bit Base + 0x00C4
DSI transmit comparison register DSPIx_COMPR 32-bit Base + 0x00C8
Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)
Register Description Register Name
Used
Size
Address Reference
