MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
Freescale Semiconductor A-57
RFIFO 1 register 3 EQADC_RF1R3 32-bit Base + 0x034C
Reserved — — Base + (0x0350-0x037F)
RFIFO 2 register 0 EQADC_RF2R0 32-bit Base + 0x0380
RFIFO 2 register 1 EQADC_RF2R1 32-bit Base + 0x0384
RFIFO 2 register 2 EQADC_RF2R2 32-bit Base + 0x0388
RFIFO 2 register 3 EQADC_RF2R3 32-bit Base + 0x038C
Reserved — — Base + (0x0390-0x03BF)
RFIFO 3 register 0 EQADC_RF3R0 32-bit Base + 0x03C0
RFIFO 3 register 1 EQADC_RF3R1 32-bit Base + 0x03C4
RFIFO 3 register 2 EQADC_RF3R2 32-bit Base + 0x03C8
RFIFO 3 register 3 EQADC_RF3R3 32-bit Base + 0x03CC
Reserved — — Base + (0x03D0-0x03FF)
RFIFO 4 register 0 EQADC_RF4R0 32-bit Base + 0x0400
RFIFO 4 register 1 EQADC_RF4R1 32-bit Base + 0x0404
RFIFO 4 register 2 EQADC_RF4R2 32-bit Base + 0x0408
RFIFO 4 register 3 EQADC_RF4R3 32-bit Base + 0x040C
Reserved — — Base + (0x0410-0x043F)
RFIFO 5 register 0 EQADC_RF5R0 32-bit Base + 0x0440
RFIFO 5 register 1 EQADC_RF5R1 32-bit Base + 0x0444
RFIFO 5 register 2 EQADC_RF5R2 32-bit Base + 0x0448
RFIFO 5 register 3 EQADC_RF5R3 32-bit Base + 0x044C
Reserved — — Base + (0x0450-0x07FF)
ADC0 control register ADC0_CR No memory mapped
access
ADC1 control register ADC1_CR
ADC time stamp control register ADC_TSCR
ADC time base counter register ADC_TBCR
ADC0 gain calibration constant register ADC0_GCCR
ADC1 gain calibration constant register ADC1_GCCR
ADC0 offset calibration constant register ADC0_OCCR
ADC1 offset calibration constant register ADC1_OCCR
Reserved — — (Base + 0x0800)-
0xFFF8_FFFF
Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)
Register Description Register Name
Used
Size
Address Reference
