MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
A-56 Freescale Semiconductor
CFIFO 1 register 1 EQADC_CF1R1 32-bit Base + 0x0144
CFIFO 1 register 2 EQADC_CF1R2 32-bit Base + 0x0148
CFIFO 1 register 3 EQADC_CF1R3 32-bit Base + 0x014C
Reserved — — Base + (0x0150-0x017F)
CFIFO 2 register 0 EQADC_CF2R0 32-bit Base + 0x0180
CFIFO 2 register 1 EQADC_CF2R1 32-bit Base + 0x0184
CFIFO 2 register 2 EQADC_CF2R2 32-bit Base + 0x0188
CFIFO 2 register 3 EQADC_CF2R3 32-bit Base + 0x018C
Reserved — — Base + (0x0190-0x01BF)
CFIFO 3 register 0 EQADC_CF3R0 32-bit Base + 0x01C0
CFIFO 3 register 1 EQADC_CF3R1 32-bit Base + 0x01C4
CFIFO 3 register 2 EQADC_CF3R2 32-bit Base + 0x01C8
CFIFO 3 register 3 EQADC_CF3R3 32-bit Base + 0x01CC
Reserved — — Base + (0x01D0-0x01FF)
CFIFO 4 register 0 EQADC_CF4R0 32-bit Base + 0x0200
CFIFO 4 register 1 EQADC_CF4R1 32-bit Base + 0x0204
CFIFO 4 register 2 EQADC_CF4R2 32-bit Base + 0x0208
CFIFO 4 register 3 EQADC_CF4R3 32-bit Base + 0x020C
Reserved — — Base + (0x0210-0x023F)
CFIFO 5 register 0 EQADC_CF5R0 32-bit Base + 0x0240
CFIFO 5 register 1 EQADC_CF5R1 32-bit Base + 0x0244
CFIFO 5 register 2 EQADC_CF5R2 32-bit Base + 0x0248
CFIFO 5 register 3 EQADC_CF5R3 32-bit Base + 0x024C
Reserved — — Base + (0x0250-0x02FF)
RFIFO 0 register 0 EQADC_RF0R0 32-bit Base + 0x0300
RFIFO 0 register 1 EQADC_RF0R1 32-bit Base + 0x0304
RFIFO 0 register 2 EQADC_RF0R2 32-bit Base + 0x0308
RFIFO 0 register 3 EQADC_RF0R3 32-bit Base + 0x030C
Reserved — — Base + (0x0310-0x033F)
RFIFO 1 register 0 EQADC_RF1R0 32-bit Base + 0x0340
RFIFO 1 register 1 EQADC_RF1R1 32-bit Base + 0x0344
RFIFO 1 register 2 EQADC_RF1R2 32-bit Base + 0x0348
Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)
Register Description Register Name
Used
Size
Address Reference
To Next Page
