MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5

Freescale Semiconductor A-55

Interrupt and DMA control register 3 EQADC_IDCR3 16-bit Base + 0x0066

Interrupt and DMA control register 4 EQADC_IDCR4 16-bit Base + 0x0068

Interrupt and DMA control register 5 EQADC_IDCR5 16-bit Base + 0x006A

Reserved — — Base + (0x006C-0x006F)

FIFO and interrupt status register 0 EQADC_FISR0 32-bit Base + 0x0070

FIFO and interrupt status register 1 EQADC_FISR1 32-bit Base + 0x0074

FIFO and interrupt status register 2 EQADC_FISR2 32-bit Base + 0x0078

FIFO and interrupt status register 3 EQADC_FISR3 32-bit Base + 0x007C

FIFO and interrupt status register 4 EQADC_FISR4 32-bit Base + 0x0080

FIFO and interrupt status register 5 EQADC_FISR5 32-bit Base + 0x0084

Reserved — — Base + (0x0088-0x008F)

CFIFO transfer counter register 0 EQADC_CFTCR0 16-bit Base + 0x0090

CFIFO transfer counter register 1 EQADC_CFTCR1 16-bit Base + 0x0092

CFIFO transfer counter register 2 EQADC_CFTCR2 16-bit Base + 0x0094

CFIFO transfer counter register 3 EQADC_CFTCR3 16-bit Base + 0x0096

CFIFO transfer counter register 4 EQADC_CFTCR4 16-bit Base + 0x0098

CFIFO transfer counter register 5 EQADC_CFTCR5 16-bit Base + 0x009A

Reserved — — Base + (0x009C-0x009F)

CFIFO status snapshot register 0 EQADC_CFSSR0 32-bit Base + 0x00A0

CFIFO status snapshot register 1 EQADC_CFSSR1 32-bit Base + 0x00A4

CFIFO status snapshot register 2 EQADC_CFSSR2 32-bit Base + 0x00A8

CFIFO status register EQADC_CFSR 32-bit Base + 0x00AC

Reserved — — Base + (0x00B0-0x00B3

SSI control register EQADC_SSICR 32-bit Base + 0x00B4

SSI receive data register EQADC_SSIRDR 32-bit Base + 0x00B8

Reserved — — Base + (0x00BC-0x00FF)

CFIFO 0 register 0 EQADC_CF0R0 32-bit Base + 0x0100

CFIFO 0 register 1 EQADC_CF0R1 32-bit Base + 0x0104

CFIFO 0 register 2 EQADC_CF0R2 32-bit Base + 0x0108

CFIFO 0 register 3 EQADC_CF0R3 32-bit Base + 0x010C

Reserved — — Base + (0x0110-0x013F)

CFIFO 1 register 0 EQADC_CF1R0 32-bit Base + 0x0140

Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)

Used

Size

Address Reference
