MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
Freescale Semiconductor A-37
Reserved — — (Base + 0x0714)-
0xFFF4_3FFF)
Error Correction Status Module (ECSM)
0xFFF4_0000
Reserved — — Base + (0x0000-0x0015)
Software watchdog timer control register ECSM_SWTCR
1
16-bit Base + 0x0016
Reserved — — Base + (0x0018-0x001A)
Software watchdog timer service register ECSM_SWTSR
1
8-bit Base + 0x001B
Reserved — — Base + (0x001C-0x001E)
Software watchdog timer interrupt register ECSM_SWTIR
1
8-bit Base + 0x001F
Reserved — Base + (0x0020-0x0023)
FEC Burst Optimization Master Control register FBOMCR 32-bit Base + 0x0024
Reserved — — Base + (0x0028-0x0042)
ECC configuration register ECSM_ECR 8-bit Base + 0x0043
Reserved — — Base + (0x0044-0x0046)
ECC status register ECSM_ESR 8-bit Base + 0x0047
Reserved — — Base + (0x0048-0x0049)
ECC error generation register ECSM_EEGR 16-bit Base + 0x004A
Reserved — — Base + (0x004C-0x004F)
Flash ECC address register ECSM_FEAR 32-bit Base + 0x0050
Reserved — — Base + (0x0054-0x0055)
Flash ECC master number register ECSM_FEMR 8-bit Base + 0x0056
Flash ECC attributes register ECSM_FEAT 8-bit Base + 0x0057
Flash ECC data register high ECSM_FEDRH 32-bit Base + 0x0058
Flash ECC data register low ECSM_FEDRL 32-bit Base + 0x005C
RAM ECC address register ECSM_REAR 32-bit Base + 0x0060
Reserved — — Base + (0x0064-0x0065)
RAM ECC master number register ECSM_REMR 8-bit Base + 0x0066
RAM ECC attributes register ECSM_REAT 8-bit Base + 0x0067
RAM ECC data register high ECSM_REDRH 32-bit Base + 0x0068
RAM ECC data register low ECSM_REDRL 32-bit Base + 0x006C
Reserved — — (Base + 0x0070)-
0xFFF4_3FFF
Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)
Register Description Register Name
Used
Size
Address Reference
