System Interface Unit (SIU)
MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
6-56 Freescale Semiconductor
Figure 6-56. CNRXC_PCSD[4]_GPIO[88] Pad Configuration Register (SIU_PCR88)
Refer to Table 6-16 for bit field definitions.
6.3.1.12.45 Pad Configuration Register 89 (SIU_PCR89)
The SIU_PCR89 register controls the pin function, direction, and static electrical attributes of the
TXDA_GPIO[89] pin.
Figure 6-57. TXDA_GPIO[89] Pad Configuration Register (SIU_PCR89)
Refer to Table 6-16 for bit field definitions.
Address: Base + 0x00F0 Access: Read / write[4:7, 10:15]
0123456789101112131415
R 0000
PA OBE
1
1
When configured as CNRXC or PCS, the OBE bit has no effect. When configured as GPO, set the OBE bit to 1.
IBE
2
2
When configured as CNRXC or PCS or GPO, set the IBE bit to 1 to reflect the pin state in the corresponding GPDI register.
Clear the IBE to 0 to reduce power consumption. When configured as GPI, set the IBE bit to 1.
00
ODE HYS SRC WPE WPS
W
RESET: 0000000000000011
Address: Base + 0x00F2 Access: Read / write[5:7, 10:15]
0123456789101112131415
R 00000
PA OBE
1
1
When configured as TXDA, the OBE bit has no effect. When configured as GPO, set the OBE bit to 1.
IBE
2
2
When configured as TXDA or GPO, set the IBE bit to 1 to reflect the pin state in the corresponding GPDI register. For SCI loop
back operation the IBE bit must be set to 1. Clear the IBE to 0 to reduce power consumption. When configured as GPI, set the
IBE bit to 1.
00
ODE HYS SRC WPE WPS
W
RESET: 0000000000000011
