System Interface Unit (SIU)
MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
6-66 Freescale Semiconductor
6.3.1.12.64 Pad Configuration Register 108 (SIU_PCR108)
The SIU_PCR108 register controls the pin function, direction, and static electrical attributes of the
PCSB[3]_SINC_GPIO[108] pin.
Figure 6-76. PCSB[3]_SINC_GPIO[108] Pad Configuration Register (SIU_PCR108)
Refer to Table 6-16 for bit field definitions.
6.3.1.12.65 Pad Configuration Register 109 (SIU_PCR109)
The SIU_PCR109 register controls the pin function, direction, and static electrical attributes of the
PCSB[4]_SCKC_GPIO[109] pin.
Figure 6-77. PCSB[4]_SCKC_GPIO[109] Pad Configuration Register (SIU_PCR109)
Refer to Table 6-16 for bit field definitions.
Address: Base + 0x0118 Access: Read / write[4:7, 10:15]
0123456789101112131415
R 0000
PA OBE
1
1
When configured as PCS or SINC, the OBE bit has no effect. When configured as GPO, set the OBE bit to 1.
IBE
2
2
When configured as PCS or SINC or GPO, set the IBE bit to 1 to reflect the pin state in the corresponding GPDI register. Clear
the IBE to 0 to reduce power consumption. When configured as GPI, set the IBE bit to 1.
00
ODE HYS SRC WPE WPS
W
RESET: 0000000000000011
Address: Base + 0x011A Access: Read / write[4:7, 10:15]
0123456789101112131415
R 0000
PA OBE
1
1
When configured as SCKC, set the OBE bit to 1 for master operation, and clear it to 0 for slave operation. When configured as
PCS, the OBE bit has no effect. When configured as GPO, set the OBE bit to 1.
IBE
2
2
When configured as SCKC in slave operation, set the IBE bit to 1. When configured as PCS or SCKC in master operation or
GPO, set the IBE bit to 1 to reflect the pin state in the corresponding GPDI register. Clear the IBE to 0 to reduce power
consumption. When configured as GPI, set the IBE bit to 1.
00
ODE HYS SRC WPE WPS
W
RESET: 0000000000000011
