System Interface Unit (SIU)
MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
6-98 Freescale Semiconductor
All bits and muxed signals on the MPC5554 are valid. The MPC5553 does not have a DSPI A port,
therefore bits 0–8 are reserved. The muxed signals used for DSPI A are invalid on the MPC5553. The
following table describes the fields for the DSPI input select register and notes the settings that are invalid
for the MPC5553.
Address: Base + 0x0908 Access: Read / write[8:31]
0123456789101112131415
R
00000000
SINSELB SSSELB SCKSELB TRIGSELB
W
Reset
0000000000000000
Address: Base + 0x0908 Access: Read / write[8:31]
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
SINSELC SSSELC SCKSELC TRIGSELC SINSELD SSSELD SCKSELD TRIGSELD
W
Reset
0000000000000000
Figure 6-133. MPC5553 DSPI Input Select Register (SIU_DISR)
Address: Base + 0x0908 Access: Read / write[0:31]
0123456789101112131415
R
SINSELA SSSELA SCKSELA TRIGSELA SINSELB SSSELB SCKSELB TRIGSELB
W
Reset
0000000000000000
Address: Base + 0x090C Access: Read / write[0:31]
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
SINSELC SSSELC SCKSELC TRIGSELC SINSELD SSSELD SCKSELD TRIGSELD
W
Reset
0000000000000000
Figure 6-134. MPC5554 DSPI Input Select Register (SIU_DISR)
