Freescale Semiconductor MPC5553 - Page 74

MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
Freescale Semiconductor 2-27
SOUTB_
PCSC[5]_
GPIO[104]
DSPI B Data Output
DSPI C Peripheral Chip Select
General Purpose I/O
P
A
G
O
O
I/O
V
DDEH6
MH – / Up – / Up N28 N23
PCSB[0]_
PCSD[2]_
GPIO[105]
DSPI B Peripheral Chip Select
DSPI D Peripheral Chip Select
General Purpose I/O
P
A
G
I/O
O
I/O
V
DDEH6
MH – / Up – / Up R27 N25
PCSB[1]_
PCSD{0]_
GPIO[106]
DSPI B Peripheral Chip Select
DSPI D Peripheral Chip Select
General Purpose I/O
P
A
G
O
I/O
I/O
V
DDEH6
MH – / Up – / Up R28 N26
PCSB[2]_
SOUTC_
GPIO[107]
DSPI B Peripheral Chip Select
DSPI C Data Output
General Purpose I/O
P
A
G
O
O
I/O
V
DDEH6
MH – / Up – / Up T28 P26
PCSB[3]_
SINC_
GPIO[108]
DSPI B Peripheral Chip Select
DSPI C Data Input
General Purpose I/O
P
A
G
O
I
I/O
V
DDEH6
MH – / Up – / Up M27 N24
PCSB[4]_
SCKC_
GPIO[109]
DSPI B Peripheral Chip Select
DSPI C Clock
General Purpose I/O
P
A
G
O
I/O
I/O
V
DDEH6
MH – / Up – / Up N27 P24
PCSB[5]_
PCSC[0]_
GPIO[110]
DSPI B Peripheral Chip Select
DSPI C Peripheral Chip Select
General Purpose I/O
P
A
G
O
I/O
I/O
V
DDEH6
MH – / Up – / Up M26 R23
eQADC Signals
AN[0]_
DAN0+
Single-Ended Analog Input
Positive Differential Analog Input
PI
V
DDA1
18
A I / – AN[0] / – C9 B7
AN[1]_
DAN0–
Single-Ended Analog Input
Negative Differential Analog Input
PI
V
DDA1
18
A I / – AN[1] / – B8 A7
AN[2]_
DAN1+
Single-Ended Analog Input
Positive Differential Analog Input
PI
V
DDA1
18
A I / – AN[2] / – G12 D9
AN[3]_
DAN1–
Single-Ended Analog Input
Negative Differential Analog Input
PI
V
DDA1
18
A I / – AN[3] / – E10 C8
AN[4]_
DAN2+
Single-Ended Analog Input
Positive Differential Analog Input
PI
V
DDA1
18
A I / – AN[4] / – C10 B8
AN[5]_
DAN2–
Single-Ended Analog Input
Negative Differential Analog Input
PI
V
DDA1
18
A I / – AN[5] / – B9 A8
AN[6]_
DAN3+
Single-Ended Analog Input
Positive Differential Analog Input
PI
V
DDA1
18
A I / – AN[6] / – G13 D10
AN[7]_
DAN3–
Single-Ended Analog Input
Negative Differential Analog Input
PI
V
DDA1
18
A I / – AN[7] / – E11 C9
AN[8]_
ANW
Single-Ended Analog Input
MUX Input
PI
V
DDA1
18
A I / – AN[8] / – E7 C4
AN[9]_
ANX
Single-Ended Analog Input
MUX Input
PI
V
DDA1
18
A I / – AN[9] / – C4 D6
Table 2-2. MPC5554 Signal Properties (Continued)
Signal Names
1
Signal Functions
2
P/
A/
G
I/O
Type
Voltage
3
Pad
Type
4
Status Pin Labels / Package
During
Reset
5
After
Reset
6
496
7
416
