Table 19-1. eQADC External Signals
Function Description
I/O
Type
Status
During
Reset
1
Status
After
Reset
2
Type Package
AN0
DAN0+
Single Ended Analog Input 0
Positive Terminal Differential Input
I I / — AN0/ — Analog 416
324
208
AN1
DAN0-
Single Ended Analog Input 1
Negative Terminal Differential Input
I I / — AN1/ — Analog 416
324
208
AN2
DAN1+
Single Ended Analog Input 2
Positive Terminal Differential Input
I I / — AN2 / — Analog 416
324
208
AN3
DAN1–
Single Ended Analog Input 3
Negative Terminal Differential Input
I I / — AN3 / — Analog 416
324
208
AN4
DAN2+
Single Ended Analog Input 4
Positive Terminal Differential Input
I I / — AN4/ — Analog 416
324
208
AN5
DAN2–
Single Ended Analog Input 5
Negative Terminal Differential Input
I I / — AN5 / — Analog 416
324
208
AN6
DAN3+
Single Ended Analog Input 6
Positive Terminal Differential Input
I I / — AN6 / — Analog 416
324
208
AN7
DAN3–
Single Ended Analog Input 7
Negative Terminal Differential Input
I I / — AN7 / — Analog 416
324
208
AN8
ANW
Single Ended Analog Input 8
External Multiplexed Analog Input W
I I / — AN8/ — Analog 416
324
208
AN9
ANX
Single Ended Analog Input 9
External Multiplexed Analog Input X
I I / — AN9 / — Analog 416
324
208
AN10
ANY
Single Ended Analog Input 10
External Multiplexed Analog Input Y
I I / — AN10/ — Analog 416
324
208
AN11
ANZ
Single Ended Analog Input 11
External Multiplexed Analog Input Z
I I / — AN11 / — Analog 416
324
208
AN12
MA0
SDS
Single Ended Analog Input 12
Mux Address 0
eQADC SSI Serial Data Select
I
O
O
I / — AN12/ — Analog/
Digital/
Digital
416
324
208
AN13
MA1
SDO
Single Ended Analog Input 13
Mux Address 1
eQADC SSI Serial Data Out
I
O
O
I / — AN13/ — Analog/
Digital/
Digital
416
324
208
