MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
2-50 Freescale Semiconductor
2.3.9.5 Analog Input / Differential Analog Input
AN[4]_DAN2+
AN[4] is a single-ended analog input to the two on-chip ADCs. DAN2+ is the positive terminal of the
differential analog input DAN2 (DAN2+ to DAN2–).
2.3.9.6 Analog Input / Differential Analog Input
AN[5]_DAN2–
AN[5] is a single-ended analog input to the two on-chip ADCs. DAN2– is the negative terminal of the
differential analog input DAN2 (DAN2+ to DAN2–).
2.3.9.7 Analog Input / Differential Analog Input
AN[6]_DAN3+
AN[6] is a single-ended analog input to the two on-chip ADCs. DAN3+ is the positive terminal of the
differential analog input DAN3 (DAN3+ to DAN3–).
2.3.9.8 Analog Input / Differential Analog Input
AN[7]_DAN3–
AN[7] is a single-ended analog input to the two on-chip ADCs. DAN3– is the negative terminal of the
differential analog input DAN3 (DAN3+ to DAN3–).
2.3.9.9 Analog Input / Multiplexed Analog Input
AN[8]_ANW
AN[8] is an analog input pin. ANW is an analog input in external multiplexed mode.
2.3.9.10 Analog Input / Multiplexed Analog Input
AN[9]_ANX
AN[9] is an analog input pin. ANX is an analog input in external multiplexed mode.
2.3.9.11 Analog Input / Multiplexed Analog Input
AN[10]_ANY
AN[10] is an analog input pin. ANY is an analog input in external multiplexed mode.
2.3.9.12 Analog Input / Multiplexed Analog Input
AN[11]_ANZ
AN[11] is an analog input pin. ANZ is an analog input in external multiplexed mode.
2.3.9.13 Analog Input / Mux Address 0 / eQADC Serial Data Strobe
AN[12]_MA[0]_SDS
AN[12]_MA[0]_SDS is an analog input pin. The alternate function, MA[0], is a MUX address pin. SDS
is the serial data strobe for the eQADC SSI; select this function by setting the PA field of SIU_PCR215 to
