10.4.3 Dene V/f characterisc shape
Various characterisc shapes are available which are described in detail in the following sub-
chapters.
Parameter
Address Name / seng range / [default seng] Info
0x2B00
(P302.00)
V/f characterisc shape
(V/f charac.shape)
•
Seng can only be changed if the inverter is inhibi-
ted.
Selecon of the V/f characterisc shape for the adaptaon to dierent
load proles.
0 Linear Linear characterisc for drives with constant load torque over the speed.
4Linear V/f characterisc ^ 178
1 Quadrac Square-law characterisc for drives with a square-law load torque over
the speed.
•
Square-law V/f characteriscs are preferably used for centrifugal
pumps and fan drives.
•
Please always check whether the corresponding drive is suitable for
operaon with a square-law V/f characterisc!
•
If your pump drive or fan drive is not suitable for operaon with a
square-law V/f characterisc, use the linear V/f characterisc instead.
4Square-law V/f characterisc ^ 179
2 Mulpoint (from version 03.00) User-denable characterisc for being adapted to special load proles.
4Adapve V/f characterisc ^ 180
3 Eco (from version 02.00) Linear characterisc with energy opmisaon in the paral load opera-
onal range.
4Energy-saving V/f characterisc (VFC-Eco) ^ 181
Conguring the motor control
V/f characterisc control for asynchronous motor (VFC open loop)
Dene V/f characterisc shape
