Lenze i550

10.6.4 Load loss detecon
This funcon serves to detect a load loss during operaon and to then acvate a specic func-
on, for instance the switching of the relay.
Details
If, during operaon, the current motor current falls below the threshold set in 0x4006:001
(P710.01) for at least the me set in 0x4006:002 (P710.02), the internal status signal "Load
loss detected [83]" is set to TRUE:
0
t
t
0x4006 001:
0x4006 002:
Load loss detected [83]
Status signal
Load [%]
•
The threshold is set in percent with reference to the rated motor current "Motor rated cur-
rent" 0x6075 (P323.00).
•
The status signal "Load loss detected [83]" can be assigned, for instance, to a digital output
or the relay via the exible I/O conguraon. 4Congure digital outputs^ 263
•
An error response can be selected in 0x4006:003 (P710.03).
•
The load loss detecon is not acve with acve DC braking.
Parameter
Address Name / seng range / [default seng] Info
0x4006:001
(P710.01)
Load loss detecon: Threshold
(Load loss detect: Threshold)
0.0 ... [0.0] ... 200.0 %
Threshold for load loss detecon.
•
100 % ≡ rated motor current 0x6075 (P323.00)
0x4006:002
(P710.02)
Load loss detecon: Delay me
(Load loss detect: Delay me)
0.0 ... [0.0] ... 300.0 s
Tripping delay for load loss detecon.
0x4006:003
(P710.03)
Load loss detecon: Error response
(Load loss detect: Error response)
•
From version 05.01
Selecon of the response following the detecon of a load loss.
Associated error code:
•
65336 | 0xFF38 - Load loss detected
0 No response
4Error types ^ 611
1 Warning
2 Trouble
3 Fault
Conguring the motor control
Parameterisable motor funcons
Load loss detecon
212
