Lenze i550

12.1.3 Dene your own control word format
The mappable data word NetWordIN1 is available for implemenng a separate control word
format.
Details
Designaon Parameter Associated mapping
entry *
Further informaon
NetWordIN1 0x4008:001 (P590.01) 0x40080110 The funcons that are to be triggered via bits 0 ... 15 of the NetWordIN1
data word are dened in 0x400E:001 (P505.01) ... 0x400E:016 (P505.16).
* A mapping entry consists of index, subindex and data length in bits of the parameter to be mapped.
General informaon about the process of data mapping can be found in the chapter of the
same name for the corresponding network.
Conguring the network
Control the inverter via network
Dene your own control word format
284
