12.2.3 Mappable parameters for exchanging setpoints and actual values
The parameters listed in the following can also be mapped to network registers, in order to
transfer set points and actual values via the network.
•
The parameters are always available irrespecve of the network opon.
•
Several parameters with dierent resoluons are available for selecon to transfer the fre-
quency setpoint and actual value.
•
The use of these parameters for the transmission of process data is oponal. It is also pos-
sible to use only a selecon of the parameters.
Parameter
Address Name / seng range / [default seng] Info
0x400B:003
(P592.03)
Process input data: Network setpoint frequency (0.1)
(Process data IN: Net.freq. 0.1)
0.0 ... [0.0] ... 599.0 Hz
Mappable parameter for specifying the frequency setpoint in [0.1 Hz] via
network.
•
The specicaon is made without sign (irrespecve of the rotang
direcon).
•
The rotang direcon is specied via the control word.
•
Example: 456 ≡ 45.6 Hz
0x400B:004
(P592.04)
Process input data: Network setpoint speed
(Process data IN: Net.setp. speed)
0 ... [0] ... 50000 rpm
Mappable parameter for specifying the setpoint as speed in [rpm] via
network.
•
The specicaon is made without sign (irrespecve of the rotang
direcon).
•
The rotang direcon is specied via the control word.
•
Example: 456 ≡ 456 rpm
0x400B:005
(P592.05)
Process input data: Network setpoint frequency (0.01)
(Process data IN: Net.freq. 0.01)
0.00 ... [0.00] ... 599.00 Hz
Mappable parameter for specifying the frequency setpoint in [0.01 Hz]
via network.
•
The specicaon is made without sign (irrespecve of the rotang
direcon).
•
The rotang direcon is specied via the control word.
•
Example: 456 ≡ 4.56 Hz
0x400B:009
(P592.09)
Process input data: Torque scaling
(Process data IN: Torque scaling)
-128 ... [0] ... 127
•
From version 02.00
Scaling factor for torque setpoint 0x400B:008 (P592.08) and actual tor-
que value 0x400C:007 (P593.07) via network.
•
With the seng 0, no scaling takes place.
Example:
•
Scaled actual torque value (0x400C:007) = 345 [Nm]
•
Scaling factor (0x400B:009) = 3
•
Actual torque value = 345 [Nm] / 23 = 43.125 [Nm]
0x400B:012
(P592.12)
Process input data: Network setpoint frequency
[0.02Hz]
(Process data IN: NetSereq0.02Hz)
-29950 ... [0] ... 29950 Hz
•
From version 04.00
Mappable parameter for specifying the frequency setpoint in [0.02 Hz]
via network.
•
The specicaon is made without sign (irrespecve of the rotang
direcon).
•
The rotang direcon is specied via the control word.
•
Examples: 50 ≡ 1 Hz, 100 ≡ 2 Hz
0x400B:013
(P592.13)
Process input data: Network frequency setpoint
[+/-16384]
(Process data IN: N.FrqSet+/-16384)
-16384 ... [0] ... 16384
•
From version 05.00
Mappable parameter for specifying the frequency setpoint via network.
•
±16384 ≡ ±100 % Maximum frequency 0x2916 (P211.00)
0x400C:003
(P593.03)
Process output data: Frequency (0.1)
(Process data OUT: Frequency (0.1))
•
Read only: x.x Hz
Mappable parameter for the output of the actual frequency value in
[0.1 Hz] via network.
•
The output is eected without sign (irrespecve of the rotang direc-
on).
•
The rotang direcon is specied via the status word.
•
Example: 456 ≡ 45.6 Hz
0x400C:004
(P593.04)
Process output data: Motor speed
(Process data OUT: Motor speed)
•
Read only: x rpm
Mappable parameter for the output of the actual value as speed in [rpm]
via network.
•
The output is eected without sign (irrespecve of the rotang direc-
on).
•
The rotang direcon is specied via the status word.
•
Example: 456 ≡ 456 rpm
0x400C:006
(P593.06)
Process output data: Frequency (0.01)
(Process data OUT: Frequency 0.01)
•
Read only: x.xx Hz
Mappable parameter for the output of the actual frequency value in
[0.01 Hz] via network.
•
The output is eected without sign (irrespecve of the rotang direc-
on).
•
The rotang direcon is specied via the status word.
•
Example: 456 ≡ 4.56 Hz
