Lenze i550

Address Name / seng range / [default seng] Info
0x2859:005
(P515.05)
PROFINET monitoring: Invalid process data
(PROFINET monit.: Inval. proc.data)
•
From version 02.00
Selecon of the response triggered by the recepon of invalid process
data.
Process data marked as invalid (IOPS is "BAD") are received by the IO
Controller. Typically in case of
•
a PLC in STOP state,
•
alarms,
•
acyclic demand data.
Corresponding error code: 33171 | 0x8193 "PROFINET: Invalid cyclic
process data"
Associated error code:
•
33171 | 0x8193 - Network: invalid cyclic process data
0 No response
4Error types ^ 611
1 Warning
2 Trouble
3 Fault
12.16.6 Diagnoscs
12.16.6.1 LED status display
Notes on the connecon status to the IO-Controller can be obtained via the LEDs "BUS RDY"
and "BUS ERR" of the PROFINET opon (on the front of the inverter).
In addion, the LEDs "Link" and "Acvity" at the RJ45 sockets indicate the connecon status to
the network.
LED "BUS RDY" (green)
Blinking paern State Meaning
O Not connected No connecon to the IO-Controller
Blinking
Connected IO-Controller in STOP
On
Data exchange IO-Controller in RUN (DATA_EXCHANGE)
LED "BUS ERR" (red)
Blinking paern State Meaning
O No fault No fault
ickers
IO-Device idenes (localises) The PROFINET funcon "node ashing test" is
triggered by IO-Controller. The ickering LED
serves to idenfy (locate) an accessible IO-
Device.
Blinking
Impermissible sengs Impermissible sengs: Stack, staon name or
IP parameters are invalid.
On (red)
Fault Communicaon error (e. g. Ethernet cable
removed)
12.16.6.2 Informaon on the network
The following parameters show informaon on the network.
Parameter
Address Name / seng range / [default seng] Info
0x2382:001
(P511.01)
Acve PROFINET sengs: IP address
(PROFINET diag.: IP address)
•
Read only
•
From version 02.00
Display of the acve IP address.
0x2382:002
(P511.02)
Acve PROFINET sengs: Subnet
(PROFINET diag.: Subnet)
•
Read only
•
From version 02.00
Display of the acve subnet mask.
0x2382:003
(P511.03)
Acve PROFINET sengs: Gateway
(PROFINET diag.: Gateway)
•
Read only
•
From version 02.00
Display of the gateway address.
Conguring the network
PROFINET
Monitoring
492
