Lenze i550

10.7.2 Automac motor calibraon (non-energized)
If the applicaon does not enable you to energise the system during the opmisaon, carry
out this opmisaon.
Precondions
•
All rated motor data is known and set in the inverter, either by selecng the motor from
the motor catalogue or manually.
4Select motor from motor catalogue ^ 51
4Manual
seng of the motor data ^ 52
•
In 0x2C00 (P300.00), the motor control type required and suitable for the motor is selec-
ted.
•
The inverter is error-free and in the "Ready to switch on" or "Switched on" device state.
•
The inverter is disabled or the motor is stopped (no start enable).
•
No other axis command is acve anymore.
Required steps
Opmisaon with engineering tool (e. g. »EASY Starter«):
1.
Go to the "Sengs" tab and navigate to the parameterisaon dialog "Advanced motor set-
ting".
2.
Click the Non-energized buon under "motor calibraon".
3.
Follow the instrucons of the engineering tool.
Opmisaon with keypad:
•
0x2822:005 (P327.05) Set = "1" to start the process.
Parameter
Address Name / seng range / [default seng] Info
0x2822:005
(P327.05)
Calibrate motor data (non-energized)
(Calibrate mot.)
0 ... [0] ... 1
1 = start automac calibraon of the motor data.
•
A default inverter characterisc is loaded.
•
the motor equivalent circuit diagram data and controller sengs are
calculated on the basis of the currently set rated motor data.
•
The motor is not energised.
Opmisaon process
As soon as the process has been started, the following steps are iniated:
1.
A default inverter characterisc is loaded.
2.
The motor equivalent circuit diagram data is calculated based on the currently set rated
motor data.
3.
The motor controller sengs are automacally calculated.
4.
The speed controller sengs are automacally calculated.
Conguring the motor control
Opons for opmising the control loops
Automac motor calibraon (non-energized)
218
