Lenze i550

Address Name / seng range / [default seng] Info
0x400C:007
(P593.07)
Process output data: Torque scaled
(Process data OUT: Torque scaled)
•
Read only
•
From version 02.00
Mappable parameter for the output of the actual torque value in [Nm /
2
scaling factor
] via network.
•
The scaling factor can be set in 0x400B:009 (P592.09).
•
Actual torque value = scaled actual torque value (0x400C:007) / 2
scaling
factor
Example:
•
Scaled actual torque value (0x400C:007) = 345 [Nm]
•
Scaling factor (0x400B:009) = 3
•
Actual torque value = 345 [Nm] / 2
3
= 43.125 [Nm]
0x400C:008
(P593.08)
Process output data: Frequency [0.02 Hz]
(Process data OUT: Frequency 0.02Hz)
•
Read only: Hz
•
From version 04.00
Mappable parameter for the output of the actual frequency value in
[0.02 Hz] via network.
•
The output is eected without sign (irrespecve of the rotang direc-
on).
•
The rotang direcon is specied via the status word.
•
Examples: 50 ≡ 1 Hz, 100 ≡ 2 Hz
0x400C:009
(P593.09)
Process output data: Frequency [+/-16384]
(Process data OUT: Freq. [+/-16384])
•
Read only
•
From version 05.00
Mappable parameter for the output of the actual frequency value via
network.
•
±16384 ≡ ±100 % Maximum frequency 0x2916 (P211.00)
Conguring the network
Dene setpoint via network
Mappable parameters for exchanging setpoints and actual values
