Lenze i550

Parameter
Address Name / seng range / [default seng] Info
0x4008:001
(P590.01)
Process input words: NetWordIN1
(NetWordINx: NetWordIN1)
0x0000 ... [0x0000] ... 0xFFFF
Mappable data word for exible control of the inverter via network.
Bit 0 Mapping bit 0 Assignment of the funcon: 0x400E:001 (P505.01)
Bit 1 Mapping bit 1 Assignment of the funcon: 0x400E:002 (P505.02)
Bit 2 Mapping bit 2 Assignment of the funcon: 0x400E:003 (P505.03)
Bit 3 Mapping bit 3 Assignment of the funcon: 0x400E:004 (P505.04)
Bit 4 Mapping bit 4 Assignment of the funcon: 0x400E:005 (P505.05)
Bit 5 Mapping bit 5 Assignment of the funcon: 0x400E:006 (P505.06)
Bit 6 Mapping bit 6 Assignment of the funcon: 0x400E:007 (P505.07)
Bit 7 Mapping bit 7 Assignment of the funcon: 0x400E:008 (P505.08)
Bit 8 Mapping bit 8 Assignment of the funcon: 0x400E:009 (P505.09)
Bit 9 Mapping bit 9 Assignment of the funcon: 0x400E:010 (P505.10)
Bit 10 Mapping bit 10 Assignment of the funcon: 0x400E:011 (P505.11)
Bit 11 Mapping bit 11 Assignment of the funcon: 0x400E:012 (P505.12)
Bit 12 Mapping bit 12 Assignment of the funcon: 0x400E:013 (P505.13)
Alternavely, this mapping bit can be used for controlling the digital out-
puts.
Assignment of the digital outputs:
•
Relay: 0x2634:001 (P420.01) / selecon [30]
•
Digital output 1: 0x2634:002 (P420.02) / selecon [30]
•
Digital output 2: 0x2634:003 (P420.03) / selecon [30]
Note!
Do not assign the mapping bit to a funcon and a digital output at the
same me. A double assignment can cause an unpredictable drive
behaviour!
Bit 13 Mapping bit 13 Assignment of the funcon: 0x400E:014 (P505.14)
Alternavely, this mapping bit can be used for controlling the digital out-
puts.
Assignment of the digital outputs:
•
Relay: 0x2634:001 (P420.01) / selecon [31]
•
Digital output 1: 0x2634:002 (P420.02) / selecon [31]
•
Digital output 2: 0x2634:003 (P420.03) / selecon [31]
Note!
Do not assign the mapping bit to a funcon and a digital output at the
same me. A double assignment can cause an unpredictable drive
behaviour!
Bit 14 Mapping bit 14 Assignment of the funcon: 0x400E:015 (P505.15)
Alternavely, this mapping bit can be used for controlling the digital out-
puts.
Assignment of the digital outputs:
•
Relay: 0x2634:001 (P420.01) / selecon [32]
•
Digital output 1: 0x2634:002 (P420.02) / selecon [32]
•
Digital output 2: 0x2634:003 (P420.03) / selecon [32]
Note!
Do not assign the mapping bit to a funcon and a digital output at the
same me. A double assignment can cause an unpredictable drive
behaviour!
Bit 15 Mapping bit 15 Assignment of the funcon: 0x400E:016 (P505.16)
Alternavely, this mapping bit can be used for controlling the digital out-
puts.
Assignment of the digital outputs:
•
Relay: 0x2634:001 (P420.01) / selecon [33]
•
Digital output 1: 0x2634:002 (P420.02) / selecon [33]
•
Digital output 2: 0x2634:003 (P420.03) / selecon [33]
Note!
Do not assign the mapping bit to a funcon and a digital output at the
same me. A double assignment can cause an unpredictable drive
behaviour!
Conguring the network
Control the inverter via network
Dene your own control word format
