Lenze i550

Address Name / seng range / [default seng] Info
0x1030:002 NMT_InterfaceGroup_0h_REC: InterfaceDescrip-
on_VSTR
•
Read only
•
From version 05.00
Display of the descripon of the Ethernet interface.
0x1030:003 NMT_InterfaceGroup_0h_REC: InterfaceType_U8
•
Read only
•
From version 05.00
Display of the interface type.
0x1030:004 NMT_InterfaceGroup_0h_REC: InterfaceMtu_U32
•
Read only
•
From version 05.00
Display of the maximum frame size.
0x1030:005 NMT_InterfaceGroup_0h_REC: InterfacePhysAddress_
OSTR
•
Read only
•
From version 05.00
Display of the MAC address of the Ethernet interface.
0x1030:006 NMT_InterfaceGroup_0h_REC: InterfaceName_VSTR
•
Read only
•
From version 05.00
Symbolic name of the Ethernet interface.
0x1030:007 NMT_InterfaceGroup_0h_REC: InterfaceOper-
State_U8
•
Read only
•
From version 05.00
Display of the operaon status of the Ethernet interface.
0x1030:008 NMT_InterfaceGroup_0h_REC: InterfaceAdmin-
State_U8
0 ... [0] ... 1
•
From version 05.00
Administraon status of the Ethernet interface.
0x1030:009 NMT_InterfaceGroup_0h_REC: Valid_BOOL
0 ... [0] ... 1
•
From version 05.00
Release of the interface descripon.
0x1E40:001 NWL_IpAddrTable_0h_REC: IfIndex_U16
•
Read only
•
From version 05.00
Display of the LF index which clearly idenes the Ethernet interface.
0x1E40:002 NWL_IpAddrTable_0h_REC: Addr IPAD
•
Read only
•
From version 05.00
Display of the IP address of the Ethernet interface.
0x1E40:003 NWL_IpAddrTable_0h_REC: NetMask_IPAD
•
Read only
•
From version 05.00
Display of the network mask of the Ethernet interface.
0x1E40:004 NWL_IpAddrTable_0h_REC: ReasmMaxSize_U16
•
Read only
•
From version 05.00
Display of the maximum frame size which can be reconstructed by
frames that arrive in a fragmented way.
0x1E40:005 NWL_IpAddrTable_0h_REC: DefaultGateway_IPAD
0 ... [0] ... 4294967295
•
From version 05.00
Display of the IP address of the router that connects the POWERLINK
segment to the higher-level network.
0x1E4A:001 NWL_IpGroup_REC: Forwarding_BOOL
•
Read only
•
From version 05.00
Display whether the IP router funcon ("Forwarding") is supported or
not.
0x1E4A:002 NWL_IpGroup_REC: DefaultTTL_U16
0 ... [64] ... 65535
•
From version 05.00
Time-to-live value which is entered into the IP header of frames to be
sent.
•
If the frame passes a router or a gateway, the me-to-live value in the
IP header is reduced by 1. As soon as the value is set to 0, the frame is
not valid anymore and is discarded.
0x1E4A:003 NWL_IpGroup_REC: ForwardingDatagrams_U32
•
Read only
•
From version 05.00
Display of the number of frames received that were determined for a
dierent IP address.
•
As the device does not support the IP router funcon, this value is
always 0.
Conguring the network
POWERLINK
Diagnoscs
453
