Output frequency
Jog reverse (CCW)
Jog foward (CW)
Run
Input signals
Frequency setpoint selection
FunctionTrigger
The status signals can be assigned to digital outputs. 4Congure digital outputs ^ 263
①
If "Jog foward (CW)" and "Jog reverse (CCW)" are acvated at the same me, the motor is stopped with the stop method set in 0x2838:003
(P203.03) and the jog operaon must be triggered again.
②
The jog operaon cannot be terminated with the "Run" funcon but only by cancelling the jog command.
Start, stop and rotang direcon commands
Flexible I/O conguraon of the start, stop and rotang direcon commands
Example: Jog forward/Jog reverse
