1055
Program
Number
Program Name/Description
Input Data
Default
20-46-11
Security Sensor Setup – Interval of Auto
Dial
Assign interval between Auto Dial when making
emergency call.
Security Sensor No.
1 ~ 8
0 = No Call
1 ~ 3600 seconds
0
20-46-12
Security Sensor Setup – General Purpose
Relay Contact Detector Circuit Setup
Define general purpose relay contact detector
circuit number (programmed in Program 10-41)
for connect security sensor.
Security Sensor No.
1 ~ 8
0 = Not Used
1 ~ 8 = Detect Circuit Number
0
20-47-01
Time Pattern Setting for Watch Mode –
Watch Mode
Define watch mode on/off against time pattern
1 ~ 8.
Time Pattern 1 ~ 8:
0 =Off
1 = On
0
20-48-01
Time Pattern for Security Sensor – Security
Sensor
Define security sensor on/off against time
pattern 1 ~ 8.
Time Pattern 1 ~ 8:
0 =Off
1 = On
0
20-55-01
Delay Timer for Security Sensor – Sensor
Delay Timer
Assign the delay time, when the contact
detection start to work after set the security
sensor. The sensor starts at once in case of set
0.
0 ~ 3600 seconds
60
35-02-22
SMDR Output Options – Security Auto
Dialing
Select whether the system should display the
SAD (Security Auto Dialing) on SMDR report.
SMDR Port 1 ~ 8:
0 = No Output
1 = Output
0
35-02-23
SMDR Output Options – Watch Auto Dialing
Select whether the system should display the
WAD (Warning Auto Dialing) on SMDR report.
SMDR Port 1 ~ 8:
0 = No Output
1 = Output
0
90-10-01
System Alarm Setup – Alarm Type
Set the alarm type 31, 32, 33. Alarm 31 – Auto
dialing after sensor detection.
Alarm 32 – Auto Dialing for Remote Watch
function.
Alarm 33 – Fail to auto dialing of security
function.
0 = Not Set
1 = Major Alarm
2 = Minor Alarm
0
90-10-02
System Alarm Setup – Report
Assign whether or not the alarm information is
reported to the predefined destination in
Program 90-11.
0 = No Report (no autodial)
1 = Report (autodial)
0
90-20-11
Traffic Report Data Setup – Security Sensor
Dial Record
Assign whether or not the security sensor dial
report is recorded for Record Security sensor
dialing and Remote Inspection dialing.
0 = Not Record
1 = Record
0
Operation
Warning Message (Watch Mode)
< Program >
