Module Descriptions
GARD 8000 SYS RFL Electronics
April 23, 2015 6-6 973.334.3100
Table 6-2. Controls and indicators for the GARD 8000 Controller Module
Reference
Designation
Description
Function
DS1
LED indicator
Indicates status of System Boot as follows:
Solid Green indicates final boot completed.
(Operating system and application software is running)
Intermediate boot stages are indicated by other colors.
DS2
LED indicator
For factory diagnostics only.
DS3
LED indicator
Indicates state of redundancy control as follows:
Solid Green = The Controller Module is OK, and is ACTIVE.
(The module has determined that its own on-board systems are operating
correctly, and the module is currently active).
Blinking Green = The Controller Module is OK, and is NOT ACTIVE.
(The module has determined that its own on-board systems are operating
correctly, and the module is currently inactive, but ready to take over if the
other, currently active, companion Controller Module fails or is disabled).
Following power-up or restart, there are two situations in the above
mode:
First: Blinking Green/Orange: The first configuration transfer
from the Active to the Inactive module did not complete yet. If
the currently active module fails or is deactivated at this time,
the inactive module will take over, but the chassis configuration
may be incorrect.
Then: Blinking Green/with no other color: Once the first
configuration transfer from the Active to the Inactive module
completes, the indicator color turns to green only. The inactive
module is fully ready.
Solid Orange = The Controller Module is NOT OK, and is ACTIVE.
(The module has detected an on-board fault, however, it continues operating
because of other considerations. For example, when there is no other
Controller present or the other Controller is also faulty)
Red = The Controller Module is NOT OK, and is NOT ACTIVE.
The module has detected an on-board fault and is not functional.
DS4
LED indicator
For factory diagnostics only.
SW1
Push Button Switch
For factory use only.
SW2
Toggle Switch
Normal Mode = Normal operation
Disable Mode = Initiates a request to take the Controller Module off-line
J9
Jumper
Watchdog Disable Jumper (RFL Service use only)
6.1.2 REDUNDANCY CONTROL
