Module Descriptions
GARD 8000 SYS RFL Electronics
April 23, 2015 6-38 973.334.3100
Table 6-15. Characteristics of GARD 8000 Long Haul Fiber Units
Assembly
Number
Type
Wavelength/
Mode
Connector
Type
Receiver
Sensitivity
(average)
TX Power
(average)
System Gain
Typical
Distance
(3dB margin)
500880
LED
Emitter/
Detector
1300 nm/
singlemode
ST
-39dBm
-17dBm
22dB
18 mi (29 km)
500885
Laser
Emitter/
Detector
1300 nm/
singlemode
ST
-39dBm
0dBm
39dB
36.5 mi (59 km)
500890
Laser
Emitter/
Detector
1550 nm/
singlemode
ST
-39dBm
-3dBm
36dB
63 mi (102 km)
500890-1
Laser
Emitter/
Detector
(2mW)
1550 nm/
singlemode
ST
-39dBm
0dBm
39dB
68 mi (110 km)
Table 6-16. Characteristics of GARD 8000 Short Haul Module, Multimode Fiber Heads (C37.94) at 25ºC
Assembly
Number
Type
Wavelength/
Mode
Connector
Type
Receiver
Sensitivity
(average)
Tx Power (average)
Typical
Distance
(3dB margin)
500875
LED
Emitter/
Detector
820 nm/
multimode
ST
-11dBm to -32dBm
-11dBm to -23dBm
Average into
50μm fiber
-11dBm to -19dBm
Average into 62.5μm
fiber
Up to 1.2
mi (2km.)
Table 6-17. Characteristics of GARD 8000 Short Haul Module, Single Mode Fiber Heads (C37.94) at 25ºC
Assembly
Number
Type
Wavelength/
Mode
Connector
Type
Receiver
Sensitivity
(average)
Tx Power
(average)
Typical
Distance
(3dB margin)
500875-1
LED
Emitter/
Detector
1300 (+/- 30 nm)
singlemode
ST
-35dBm
-20dBm to -22dBm
Average into 9μm
fiber
Up to 6.2 mi
(10km)
