Module Descriptions
GARD 8000 SYS RFL Electronics
April 23, 2015 6-42 973.334.3100
Table 6-19. GARD 8000 Power Supply Specifications
Power Supply
Specifications

500305
500315
500325
Input Voltage
Range
48-125 Vdc or 120 Vac
200-300 Vdc or 220 Vac
19-29 Vdc
Max Output
Current:
+18V
-18V
4.00 Amps (combined total)
4.00 Amps (combined total)
4.00 Amps (combined total)
Adjustments:
none
none
none
Test Points:
TP1
TP2
TP3
+18 Volts nominal
Common
-18 Volts nominal
+18 Volts nominal
Common
-18 Volts nominal
+18 Volts nominal
Common
-18 Volts nominal
Indicators
DS1 – Normal (Green)
DS1 – Normal (Green)
DS1 – Normal (Green)
Fuses
F1
F2
Input + 4A, 250 V SLO-BLO
(3AG ¼ x 1¼)
Input- 4A, 250 V SLO-BLO
(3AG ¼ x 1¼)
Input+ 2A, 250 V SLO-BLO
(3AG ¼ x 1¼)
Input- 2A, 250 V SLO-BLO
(3AG ¼ x 1¼)
Input + 10A, 32 V SLO-BLO
(3AG ¼ x 1¼)
Input- 10A, 32 V SLO-BLO
(3AG ¼ x 1¼)
Operating
Temperature
-20
o
C to +70
o
C
-20
o
C to +70
o
C
-20
o
C to +70
o
C
Humidity
95% @ +40
o
C
95% @ +40
o
C
95% @ +40
o
C
Isolation
2500 Vdc isolation from input
terminals to ground, and input
terminals to output terminals.
2500 Vdc isolation from input
terminals to ground, and input
terminals to output terminals.
2500 Vdc isolation from input
terminals to ground, and input
terminals to output terminals.
