3.5 SPECIFICATIONS FOR THE 9508 RF CHASSIS (OPTION)
3.5.1 50W POWER AMPLIFIER
Number Of Inputs: One or Two.
Input Level:
+4dBm@75 Ohms - single input,
+1dBm@75 Ohms - two inputs.
Input Impedance: 75 Ohms nominal.
Idle Noise: -65 dBmO, measured in a 3-kHz bandwidth.
Frequency Response: Flat within +/-2.0dB from 20kHz to 500 kHz
Third Order Intermodulation Distortion:
From 60 to 350 kHz: -60 dBmO.
Below 500kHz: -50 dBmO.
Harmonic Distortion: -40 dB.
Maximum Output: 50 Watts PEP
Output Impedance: 50 Ohms nominal.
Input Power:
+92Vdc@ 2.0 Amps
+30 Vdc@ 0.2 Amps
Operating Temperature: -20
o
C to +65
o
C (-4
o
F to +149
o
F).
Dimensions:
5.2 inches (13.2 cm)high
17.1 inches (43.4 cm)wide
4.3 inches (10.9 cm)deep
3.5.2 POWER AMPLIFIER, POWER SUPPLY
Input Voltage Range:
107250-4: 38 Vdc to 150 Vdc
107250-5 200 Vdc to 300 Vdc
Output Power:
30 Vdc@ 0.25 Amps
92 Vdc@ 2.4 Amps
Operating Temperature: -20
o
C to +65
o
C (-4
o
F to +149
o
F).
Humidity: +95% @ +40
o
degC.
