Offset Potentiometer

Scale Potentiometer

Figure 10-7. PLC Digital Module (500455-1)

The Offset and Scale potentiometers on the PLC Digital Module are factory set and should not

normally need adjustment. However, if changes are made to either the digital board or CLI meter the

scale can be reset as shown below.

Note: This adjustment should only occur after the receive commissioning procedure has been

completed, see section 4.6.3.3.

1. Set the RX level to a non 0 dB level relative to nominal (the further from 0 dB without

exceeding the range of the meter the better).

2. Adjust R237 (Scale) such that the meter displays the relative level of the RX signal.
