Installation and Commissioning
GARD 8000 SYS RFL Electronics
November 28, 2017 4-16 973.334.3100
Table 4-9. GARD 8000 modules, general information – Cont….
Module Description
Assy.
Number
Location of Module in GARD 8000
Chassis – Front or Rear
For Additional
Information
see Paragraph:
Comms I/O Base
500850
R
6.8
RS-499,X21, V35 Comms Unit
500855
Plugs into Comms I/O Base
6.8
G.703 Comms Unit
500860
Plugs into Comms I/O Base
6.8
T1/E1 100/120 Ohm Unit
500865
Plugs into Comms I/O Base
6.8
E1 75 Ohm (BNC) Unit
500870
Plugs into Comms I/O Base
6.8
C37.94 Unit
500875
Plugs into Comms I/O Base
6.8
Fiber Unit, 1300nm LED
500880
Plugs into Comms I/O Base
6.8
Fiber Unit, 1300nm Laser
500885
Plugs into Comms I/O Base
6.8
Fiber Unit, 1550nm LED
500890
Plugs into Comms I/O Base
6.8
RS-232 Async Comms Unit
500945
Plugs into Comms I/O Base
6.8
Current Differential Relay I/O
500925
R
Section 13
Power Line Carrier (Analog Module)
500930
R (Requires 500455 in Front Slot)
6.5.2
Ethernet TPS Module
500895
R
Section 14
4.6 COMMISSIONING PROCEDURES
4.6.1 TELEPROTECTION COMMISSIONING
