SECTION 7. CHASSIS CONFIGURATION SETTINGS
7.1 NAVIGATING SECTION 7
The GARD Protective Relay and Communications System is normally configured at the factory to
meet each customer’s specific requirements. If changes or additions are required, the following
alphabetical list will assist users familiar with the GARD’s capabilities to go directly to the
configuration web screens for setting information. Users new to the GARD should review Section 7
before configuring a particular GARD function.
Note that the table below lists most of the settings for various modules in the GARD Chassis.
Settings for the Current Differential, Ethernet TPS, Optional Metering Module and DNP Option
are listed in their respective sections.
Function
Page Number
Alarm Configuration
7-93
Async Comms Configuration
7-37
Audio Tone Teleprotection Configuration Settings
7-43
Communication System Configuration
7-9
Editing HMI Bit Labels
7-91
File Operations
7-98
Input Mapping
7-107
Input Module Settings
7-3
LED Logic Assignments
7-81
Logic Bit Labels
7-89
Optional Settings (Logic)
7-111
Output Mapping
7-108
Power Line Carrier Configuration
7-58
SOE System Counters
7-88
SOE Triggers and Labels
7-84
System Labels and Triggers
7-77
System Logic Configuration
7-106
Telemetry Transmitter Module Settings (Option)
7-73
Teleprotection Configuration
7-18
Teleprotection Configuration (Optional 96-Bit System)
7-27
Time Slot Settings
7-30
Time Slot Settings (Optional 96-Bit System)
7-32
Timer Settings
7-113
