Table 6-4. Controls and indicators for the GARD 8000 Display With TPS Module

Reference

Designation

Description

Function

DS1 to DS20

LED indicators

Front panel multi-color LEDs (Green, Red, Orange).

The function of these LEDs is programmable by the user.

Connector

RJ-45 Ethernet port

Ethernet

Status LEDs

LED No.1 displays Link and Receive Status information as follows:

Solid Green indicates Link Status is OK

Blinking Green when receiving data

LED No.2 displays Transmit Status information as follows:

LED is ON (Green) when transmitting data

SW17

Push Button

Switch

The pushbutton is a programmable function typically used to reset the front panel

LEDs.
