SECTION 18. APPLICATION NOTES
This section contains applications notes, which are intended to assist users in configuring their GARD
8000 system. In most cases the application note would be customer specific.
The following application notes are included in this section.
Application Note
Title
No. pages
Revision Date
AN8000-001
Display with 9745 Emulation
10
September 15, 2006
AN8000-002
Audio Test Panel (3U Chassis)
6
January 23, 2007
AN8000-003
Bias Setting Guidelines and Examples for the GARD 87L
(Current Diff Module)
14
June 5, 2007
AN8000-004
Special Configuration for Second PLC Module
(2-Power Supplies)
2
January 30, 2008
AN8000-005
Front Panel with CLI Meter (now included in Section 10,
PLC section)
N/A
N/A
AN8000-006
Audio Test Panel (3U Chassis) For use with 2-Audio Tone
Modules
8
May 28, 2008
AN8000-007
Latching Relay Output Unit
4
June 26, 2008
AN8000-008
Optional Switched Battery Power Supply I/O Module, Single
On-Off Switch
4
July 15, 2008
AN8000-009
Special Audio Tone Teleprotection Configuration Setting
4
September 5, 2008
AN8000-010
Special Audio Tone Teleprotection with Transparent Modem
Mode (now included in Section 6)
N/A
N/A
AN8000-011
IRIG-B Signal, through rear RS-232 port
4
September15, 2009
