8.5.3 OPTION SETTINGS
There are 5 different options for each function on the TPS. The following settings are available to the
user. In the following table, N can equal any function from 2 to 8.
Table 8-13. Option Settings
System Option Setting
Default
Description
Function N Start 1 Polarity
Normal
This sets the polarity of the start 1 input to normal or
inverted
Function N Start 2 Polarity
Normal
This sets the polarity of the start 2 input to normal or
inverted
Function N Stop 1 Polarity
Normal
This sets the polarity of the stop input to normal or inverted
Function N Start And / Or
Or
This sets whether the two start inputs are ANDed or Ored
Function N Mode
Normal
This sets whether DCB mode is enabled or not
Receive N Output polarity
Normal
This sets the polarity of the receive output to normal or
inverted
Phase A - 52A or 52B
52B
Selects whether the input is a 52A or 52B
Phase B - 52A or 52B
52B
Selects whether the input is a 52A or 52B
Phase C - 52A or 52B
52B
Selects whether the input is a 52A or 52B
BFI Polarity
Normal
Selects the polarity of the BFI input is normal or inverted
89B Polarity
Normal
Selects the polarity of the 89B input is normal or inverted
