Technical Data

GARD 8000 SYS RFL Electronics

September 24, 2012 3-6 973.334.3100

3.4 POWER LINE CARRIER SPECIFICATIONS

Modes Of Operation:

FSK 2F or 3F Operation

On/Off Normal Checkback or Hard Carrier Checkback

Number Of Active Channels:

One

Operating Band:

30Hz to 500kHz

Channel Tuning resolution:

125 Hz

Max Transmit Power:

10W

Transmit Output Impedance:

50 Ohms (75 Ohm Skewed Hybrid Available)

Max Transmit Frequency Offset:

<10 Hz

Max Level Of Spurious Emissions:

-55dBc

Maximum Receive Input Level:

25 Vrms

Receive Dynamic Range:

>40 dB

Receive Sensitivity:

5mVrms

Receive Input Impedance:

Terminated Mode 1 50 Ohms

Terminated Mode 2 75 Ohms

Unterminated > 30 K Ohms
