RFL Electronics GARD 8000 - Page 205

Module Descriptions
GARD 8000 SYS RFL Electronics
April 23, 2015 6-21 973.334.3100
Table 6-9. Continued - Jumper Settings and Switch Function for the GARD 8000 PLC Digital Module.
Reference
Designation
Description
Function
TP9
Test Point
GND: Digital ground
TP10
Test Point
GND: Digital ground
TP11
Test Point
+3.3VA: 3.3V Analog supply
TP12
Test Point
+1.6V: 1.6V DSP supply
TP13
Test Point
-5VA: -5V Analog supply
TP14
Test Point
+3.3V: +3.3V Digital supply
TP15
Test Point
+5VD: +5V Digital supply
TP16
Test Point
GNDA: Analog ground
TP17
Test Point
GNDA: Analog ground
TP18
Test Point
-15V: -15V Analog supply
TP19
Test Point
For factory use only.
TP20
Test Point
For factory use only.
TP21
Test Point
For factory use only.
TP22
Test Point
For factory use only.
TP23
Test Point
For factory use only.
TP24
Front Panel Test Point
GNDA: Analog ground
TP25
Front Panel Test Point
ADC IN: Analog to digital converter input
TP26
Front Panel Test Point
RX: Receive level after attenuation stage
TP27
Front Panel Test Point
TX OUT: Input to power amp
