Chassis Configuration Settings
GARD 8000 SYS RFL Electronics
April 1, 2012 7-5 973.334.3100
To enable an input to be linked to the logic bus, place a check in the appropriate box by clicking on the
box.
Module Enable
Select Module Enable to save the settings and to activate the I/O module in the GARD chassis.
Module Disable
Select Module Disable to save the settings and to disable the I/O module in the GARD chassis.
Start of Logic Range
This value can be obtained from the logic diagram and will establish which logic bit the module will
begin to place data onto the logic bus (3-506). Careful consideration must be given when entering
logic bit settings. Improper settings will result in a Logic Bus Error, and a unit that does not
operate properly. Logic bit assignments should never be duplicated within a chassis.
Save
Select the Save button to save the module settings without changing the module enable/disable status.
Note: Do not exit (close) the browser window before the browser has completed its operation.
Typically a message similar to the one below will display in the system tray of your
computer, do not exit until such a message is displayed.
7.2.2 ADDITIONAL INPUT MODULES
Repeat the steps from section 7.2.1 for the remaining Input modules in the chassis.
