GARD DNP Configuration and SNMP Trap Agent
GARD 8000 SYS RFL Electronics
April 23, 2015 16-14 973.334.3100
WRITE Binary Outputs Written by the Master
SELECT/OPERATE Never
DIRECT OPERATE Never
DIRECT OPERATE - NO ACK Never
Count > 1 Never
Pulse On Never
Pulse Off Never
Latch On Never
Latch Off Never
Queue Never
Clear Queue Never
Reports Binary Input Change Events when no
specific variation requested:
Never
Reports time-tagged Binary Input Change Events
when no specific variation requested:
Never
Sends Unsolicited Responses:
Programmable
Sends Static Data in Unsolicited Responses:
Never
.
Default Counter Object/Variation:
Default Object 20
Default Variation 1
Point-by-point list attached
Counters Roll Over at:
GARD system counters 32 Bits
PLC Trip counters 8 Bits
Sends Multi-Fragment Responses: Yes
Port Configuration
The DNP communication port shall be 100 Base T Ethernet or RS-485
Point List
The points available from the GARD 8000 depend on the number and type of modules installed in the
chassis. From that list, any number of points can be selected or deselected by the user.
