1 Initial jam [0 to 65535 / 0 / 1]
2 Main scan HP jam
8 Pre-registration sensor lag jam (Roll Unit 1)
9 Pre-registration sensor lag jam (Roll Unit 2)
13 DRESS sensor late jam during image registration
16 Exit sensor lag jam
34 Bypass paper set jam
41 Main scan printing jam
53 Paper out (Roll Unit 1)
54 Paper out (Roll Unit 2)
58 Pre-registration sensor lag jam
63 DRESS sensor lag jam during image registration
66 Exit sensor lag jam
84 Bypass sensor late jam
7515 Original Jam Count by Detection
1 Initial jam [0 to 65535 / 0 / 1]
2 Original registration sensor late
3 Original registration sensor off jam
4 Original registration sensor lag jam
5 Original exit sensor lag jam
6 Original stop jam
7 Original exit late jam
8 Next original set jam
7516 Paper Size Jam Count
Main SP Tables-7
149
