Ricoh MP CW2201 Service Manual

10. Align the hooks on the rear of the operation cover with the wide end of the mounting
holes and pull the cover toward you ( x2).
11. Hook the rear of the operation cover. ( x3)
12. Tighten the screws ( x2).
13. Pass the cable through the center hole of the right cover [A], and connect the USB
connector to the operation panel.
2. Installation
174

Ricoh MP CW2201 Specifications

General

Color Printing	Yes
Scan Resolution	600 dpi
Standard Interfaces	Ethernet, USB
Paper Size	A4
Operating Systems	Windows
Power Source	AC 100-240V, 50/60Hz
