7. Set a screwdriver in hole [B] and rotate it clockwise to lower the K2 and color print
head caps. Use a flashlight to confirm that the print head caps are down.
8. Once again check the gaps.
• Both the suction cap and K2/color print head caps should be down.
• Your view should not be blocked by either the suction cap or K2/color print head caps.
• To prevent damaging the caps, you must confirm that both the suction cap and K2/color
print caps are down before you push the carriage unit away from the home position.
9. Push the carriage unit away from the right side of the machine so that it is over the
paper.
4. Replacement and Adjustment
272
